The features of the custom aluminium yacht Pure 49 are a pilothouse, lifting keel, double rudder, water ballast tanks, carbon mast, fathead-mainsail, genoa, self-tacking jib, code zero, and gennaker. The Pure 49 was the inspiration for founding our shipyard, which specialises in ultra-light, fast aluminium yachts.
Pure 49
![Pure_Yachts_49.png](https://static.wixstatic.com/media/90f9ab_681a0a591ee14d9d80f09daf09fb3b20~mv2.png/v1/fill/w_600,h_800,al_c,q_90,enc_auto/Pure_Yachts_49.png)
![pure_yachts_LOA.png](https://static.wixstatic.com/media/90f9ab_78ee040ecb504b7c9fc3e8331ef59936~mv2.png/v1/fill/w_980,h_980,al_c,q_90,usm_0.66_1.00_0.01,enc_auto/pure_yachts_LOA.png)
LOA
16.00 m
52'5"
![pure_yachts_BEAM.png](https://static.wixstatic.com/media/90f9ab_74cfd085285241f98dbe7ee8209f880a~mv2.png/v1/fill/w_980,h_980,al_c,q_90,usm_0.66_1.00_0.01,enc_auto/pure_yachts_BEAM.png)
Beam
4.30 m
14'1"
![pure_yachts_MIN.png](https://static.wixstatic.com/media/90f9ab_7ef2728e117d4c35b72c643e37777267~mv2.png/v1/fill/w_980,h_980,al_c,q_90,usm_0.66_1.00_0.01,enc_auto/pure_yachts_MIN.png)
Draft min.
1.30 m
4'2"
![pure_yachts_MAX.png](https://static.wixstatic.com/media/90f9ab_07f109a5713747198bfedac5dcba8901~mv2.png/v1/fill/w_980,h_980,al_c,q_90,usm_0.66_1.00_0.01,enc_auto/pure_yachts_MAX.png)
Draft max.
3.20 m
10'5"
![pure_yachts_TLBS.png](https://static.wixstatic.com/media/90f9ab_ed94025940ce498387e5460fe2d503dd~mv2.png/v1/fill/w_980,h_980,al_c,q_90,usm_0.66_1.00_0.01,enc_auto/pure_yachts_TLBS.png)
Displacement
13 t
28,660 lbs
Exterior design
![Pure_Yachts_49.png](https://static.wixstatic.com/media/90f9ab_681a0a591ee14d9d80f09daf09fb3b20~mv2.png/v1/fill/w_600,h_800,al_c,q_90,enc_auto/Pure_Yachts_49.png)
Specification
Total Sail area | 140 m² | 1506 sqft |
Mainsail | 76 m² | 818 sqft |
Jib | 64 m² | 689 sqft |
Staysail | 29 m² | 312 sqft |
Code Zero option | 110 m² | 1184 sqft |
Gennaker option | 220 m² | 2368 sqft |
Mast length | 20.60 m | 67'5" |
LOA | 16.00 m | 52'5" |
Hull length | 15.00 m | 49'2" |
LWL | 14.40 m | 47'2" |
Beam | 4.30 m | 14'1" |
Draft min. keel lifted | 1.30 m | 4'2" |
Draft max. | 3.20 m | 10'5" |
Ballast keel | 5 t | 11,023 lbs |
Ballst tank sea water | 2 x 750 l | 2 x 165 gal |
Displacement | 13 t | 28,660 lbs |
Fuel tank | 900 l | 198 gal |
Fresh water | 300 l | 66 gal |
Black water | 150 l | 33 gal |
Engine Diesel Yanmar | 41,9 kW | 56 hp |
Cabins | 2 + 1 | |
CE Certificate | A | |
Design | Berckemeyer Yacht Design | |
Interior | Pure Yachts |
Page 1 of 1
![PureYachts_Pure422.jpg](https://static.wixstatic.com/media/90f9ab_028c5ab6e1d341eba87c23554d410a1c~mv2.jpg/v1/fill/w_100,h_66,al_c,q_80,usm_0.66_1.00_0.01,enc_auto/90f9ab_028c5ab6e1d341eba87c23554d410a1c~mv2.jpg)
![](https://static.wixstatic.com/media/90f9ab_a04204997ef24164851d2181056aed1d~mv2.png/v1/fill/w_728,h_488,al_c,q_85,enc_auto/Pure_Claim.png)
![](https://static.wixstatic.com/media/90f9ab_ac20da94414942499321e7effc4749c7~mv2.jpg/v1/fill/w_250,h_250,fp_0.50_0.50,q_30,blur_30,enc_auto/90f9ab_ac20da94414942499321e7effc4749c7~mv2.webp)
![First interior fitting](https://static.wixstatic.com/media/90f9ab_ac20da94414942499321e7effc4749c7~mv2.jpg/v1/fill/w_314,h_314,fp_0.50_0.50,q_90,enc_auto/90f9ab_ac20da94414942499321e7effc4749c7~mv2.webp)
![](https://static.wixstatic.com/media/90f9ab_7e17b73745054a75a6b405a2fb167ab8~mv2.jpg/v1/fill/w_250,h_250,fp_0.50_0.50,q_30,blur_30,enc_auto/90f9ab_7e17b73745054a75a6b405a2fb167ab8~mv2.webp)
![Team debut with Pure 42](https://static.wixstatic.com/media/90f9ab_7e17b73745054a75a6b405a2fb167ab8~mv2.jpg/v1/fill/w_314,h_314,fp_0.50_0.50,q_90,enc_auto/90f9ab_7e17b73745054a75a6b405a2fb167ab8~mv2.webp)
![](https://static.wixstatic.com/media/90f9ab_972d1f14fce34efa95069ec71a5042b6~mv2.jpg/v1/fill/w_250,h_250,fp_0.50_0.50,q_30,blur_30,enc_auto/90f9ab_972d1f14fce34efa95069ec71a5042b6~mv2.webp)
![Milestone at our shipyard](https://static.wixstatic.com/media/90f9ab_972d1f14fce34efa95069ec71a5042b6~mv2.jpg/v1/fill/w_314,h_314,fp_0.50_0.50,q_90,enc_auto/90f9ab_972d1f14fce34efa95069ec71a5042b6~mv2.webp)
![Pure_49_maindeck_custom.png](https://static.wixstatic.com/media/90f9ab_400985eb72c740f9a8678999d9843bd7~mv2.png/v1/fill/w_980,h_327,al_c,q_85,usm_0.66_1.00_0.01,enc_auto/Pure_49_maindeck_custom.png)
Main deck
Layouts
![Pure_49_lowerdeck_custom.png](https://static.wixstatic.com/media/90f9ab_e899f9e475ed401ba6dafcc626483fbb~mv2.png/v1/fill/w_980,h_327,al_c,q_85,usm_0.66_1.00_0.01,enc_auto/Pure_49_lowerdeck_custom.png)
Lower deck interior
![Pure_49_hullplan_port_custom_PDF.png](https://static.wixstatic.com/media/90f9ab_0e7a27456f594011883f369d2bb78d83~mv2.png/v1/fill/w_980,h_368,al_c,q_90,usm_0.66_1.00_0.01,enc_auto/Pure_49_hullplan_port_custom_PDF.png)
Hull plan portside
